Vacuum sweeper KM 100/100 R G

Comfortable and modern ride-on sweeper for professional use in outdoor and indoor area for areas from 8000 – 10,400 square metres/h.

NOTE: Customized Pricing provided after site and application evaluation.



Contact Us

Delivery : SKU# : 1.280-105.0

TECHNICAL DESCRIPTION: Drive: – Honda motor 6.7 kW – 1 pedal for forward and reverse motion – Small turning circle (3350 mm) – Automatic parking brake with vacuum technology – Automatic motor shutdown when you leave seat Sweeping/vacuuming system: The machine works according to the throw-over principle, i.e. the waste is transported into the dirt container at the back via the sweeper roller.The sweeper roller is floating and automatically adapted to ground unevenness. Both the filter and the main sweeper roller can be exchanged without any tools.The coarse dirt flap allows the pick-up of coarse dirt, such as cans, grit, gravel or wet leaves.The side brush and the sweeper roller are driven hydraulically.A second side brush is available as an option.Dirt container: The two 50-litre dirt containers can be removed at the side Operation: The side brush and the main sweeper roller can be lowered using a switch. Forward and reverse motion are controlled via a single pedal.

Features and benefits

Specifications

Technical data

Feature Specification
Traction drive Four-stroke engine
Drive – Power (kW) 6,7
Drive type Petrol
Max. area performance (m²/h) 8000
Max. area performance with 2 side brushes (m²/h) 10400
Working width (mm) 700
Working width with 1 side brush (mm) 1000
Working width with 2 side brushes (mm) 1300
Waste container (l) 100
Climbing ability (%) 18
Working speed (km/h) 8
Filter area (m²) 6
Weight (with accessories) (kg) 340
Weight, ready for operation (kg) 300
Dimensions (L × W × H) (mm) 2006 x 1005 x 1343

Equipment

  • Manual filter cleaning
  • Automatic filter cleaning
  • Main sweeper roller, floating
  • Suction volume regulation
  • Coarse dirt flap
  • Overhead sweeping principle
  • Traction drive, forwards
  • Traction drive, reverse
  • Suction
  • Outdoor use
  • Elapsed time counter
  • Sweeping function, can be switched off
